Product Description
Formwork made of polystyrene block filled with concrete inside that has semi industrialized placement.
Our solution for your projects with a tight and very demanding finishing schedule. Consist of two panels of foam held together with cross ties or webs which creates a block. The block is filled with Evolution® Concrete providing a load bearing structure that will provide superior structural performance compared to traditional systems.
Properties
- Formwork made of polystyrene block filled with concrete inside that has semi industrialized placement
Benefits
- Fire resistance up to 120 minutes
- Acoustic performance up to 50 Db
- Flexibility of design (No beam system required)
- Energy efficient
- Cost competitive to conventional construction system
- Superior K (0.084) value compared with concrete blocks
- Increase site productivity by speeding construction time (120 m2 per day output)
- Can score points for LEED or ESTIDAMA
Application
- Building and Housing
- Bearing Walls Panels
- Non-Bearing or Partitioning Walls
- Floor or Slab Panels
- Items which cannot be vibrated/thickened
Technical Data
| Concrete Grade (N/mm2) | 30 to 60 |
| Flow (mm) | 550 to 650 |
| Flow Retention (min) | 90 to 120 |
| Maximum Aggregate Size (mm) | 10-20 |
| Typical Density (Kg/m3) | 2,400 |
| Cement Types | OPC, SRC, MSRPC |
How to use
- ICF’s stacked on footing or slab
- Wall openings set-in utilizing bucks
- Rebar placed for reinforcement
- Braced, embeds and attachment placed
- Cavity filled and consolidated with concrete
- Interior walls, floors and roof attached
- Utilities roughed in
- Finishes applied
Performance footprint
